PD Low frequency Inverter

  • PD Low frequency Inverter
PD Low frequency Inverter
  • Product Description

Feature


◆ Pure sine wave output.

◇ Low frequency toroidal transformer lower loss.

◆ LCD/LED&LCD real-time display working status.

AC charging function, maximum charge current up to 15A, AVR AC output.

Auto select working modes: AC first, battery first and energy-saving mode.

 RS232 communication port optional.


Product Parameters


Specification
Model: PD

3511250112102241021215212/2420224/4830224/48
Rated Power350W500W1000W1000W1500W2000W3000W
Battery Voltage12VDC12VDC24VDC12VDC12/24VDC24/48VDC24/48VDC
Size(L*W*Hmm)310*240*115360*210*380
Packing Size(L*W*Hmm)370*320*200420*280*445
N.W.(kg)56813141620
G.W.(kg)(Carton Packing)67914151721
Parameter
InputDC Input Voltage Range10.5VDC-15VDC(Single battery voltage)
AC Input Voltage Range73~138VAC/145~275VAC85~138VAC/170~275VAC
AC Input Frequency Range45HZ-65HZ
OutputEfficiency≥85%
Output Voltage(Battery Mode)110VAC±2% / 220VAC±2%
Output Frequency(Battery Mode)50/60HZ±1%
Output Wave(Battery Mode)Pure Sine Wave
AC Output Voltage Range110VAC±10% / 220VAC±10%
AC Output Frequency RangeTracking Automatically
ProtectionBattery low voltage alarm10.5VDC(Single battery voltage)
Battery low voltage protection10VDC(Single battery voltage)
Battery over voltage protection17V±0.5V(Single battery voltage)
Battery over voltage alarm15VDC-16VDC(Single battery voltage)
Over power protection110% more than rated capacity
Temperature protection≥85℃ alarm,≥90℃ machine shut off
Transfer Time≤4ms
Battery TypeAccording to Customer Requirements
DisplayLCD
Thermal methodCooling fan in intelligent control
AC Charging currentMax 15A
Working Mode1 AC First(Mains first with AC charging)
2 Saving Energy Mode(Load power≤10% machine turns off,≥11%-100% machine turns on)
3 Battery First(When charging: Battery voltage ≥13V, turn converting mode;
                         When converting: Battery voltage ≤10.5V, turn mains mode. )
CommunicationRS232(Optional)
EnvironmentNoise≤55dB
Temperature-10℃~41℃
Humidity0%~95%(No condense)
Note:All specifications are subject to charge without prior notice



System connection diagram


To be added……

Applications

low frequency inverter

PD Inverter installation case
